Increase the capacity of your Yeti (1500X or larger) and power your medium to large appliances for days on end with this home backup system. Four Yeti Tank Expansion Batteries and the Yeti Link Expansion Module extend your battery capacity to roughly 4,800 Watt Hours, providing you peace of mind during the next power outage.

features

GOAL ZERO YETI HOME ENERGY STORAGE

• Customizable, versatile energy storage system backs up four essential circuits in your home and scales to meet your specific power needs.
• Our industry-leading battery chaining technology allows you to connect cost-effective lead-acid batteries to our high-quality Yeti 1500X and larger Power Stations to easily scale your energy storage capacity.
• Integrate directly with your home's circuits for a more seamless backup power experience using the Yeti Home Integration Kit. Power everything from lights in high-use rooms and fridges to medical devices, internet modems, and more.

WHAT'S IN THE BOX

• (4x) Yeti Tank Expansion Battery v3
• Yeti Link Expansion Module v3
• 120W Power Supply

tech

Yeti Link Expansion Module

CHARGE TIMES

Max Input from Yeti Tank to:

• Yeti 1500X: 454-750W
• Yeti 3000X: 750W
• Yeti 6000X: 750W

GENERAL

• Kit SKU: 44156

• Weight: 1.5 lbs (680 g)
• Dimensions: 10.25 x 3.3 x 1.5 in. (26 x 8.4 x 3.8 cm)
• Warranty 12 months
• YETI X 120W POWER SUPPLY
• Gauge: 16AWG
• Cable Length: 9 ft 4 in.
• Dimensions: 2.5 x 5.9 x 1.4 in. (6.5 x 15 x 3.5 cm)

PORTS

• Do not exceed 22V input
• 8mm Charging Port (input): 14 - 22V Do not exceed 150W (10A) per port
• External Battery Connector (output): 65A charge controller
• External Battery Connector (Input/Output): 10.7-15V. Do not exceed 15V
• YETI X 120W POWER SUPPLY
• Input: AC Wall Plug 100-240V - 50/60Hz 3.0A
• Output: 8.0mm 16V- 7.5A, 120W

Yeti Tank Expansion Battery

CHARGE TIMES

• Wall Charger (120W): 11 hours per tank

BATTERY DETAILS

• Lead Acid (AGM)
• 1200Wh (12V, 100Ah)

PORTS

• Expansion port male connector (input/output) 100A Max
• Expansion port female connector (input/output) 100A Max

GENERAL

• Dims 15.5 x 7.5 x 10.5 in. (39.37 x 19.05 x 26.67 cm)
• Weight 77.1 lbs (34.97 kg)
• Warranty: 12 Months
• Female Mp120 to ring terminal: 27 in., 8 AWG
• Male Mp120 to ring terminal: 39 in., 8 AWG
